Product parameters
Product information
| Item | P2.5 |
| Pixel pitch | 2.5mm |
| pixel density | 160000点/㎡ |
| module resolution | 64*64 |
| module size | 160*160 |
| configuration | 1R1G1B |
| Encapsulation | SMD2121 |
| Operating voltage | AC:110V-220V |
| Drive mode | 32Scan |
| Cabinet material | Die-casting Aluminum |
| Brightness | 800CD/㎡ |
| Color temperature | 2000K-9500K(adjustable) |
| Viewing angle | H:160°V:160° |
| planeness | ≥98% |
| space | ＜0.1mm |
| Max power consumption | ≤550W/㎡ |
| Average power consumption | 100W/㎡-300W/㎡ |
| Frame Frequency | 60Hz |
| Refresh Rate | 1920-3840HZ |
| Grey | 16384 |
| Protection Level | IP31 |
| Lifetime | 100000H |
| Working Temperature | 10%-90%RH |
| Operating Humidity | -10～60℃ |
| software | Windows XP,WIN7/8/10 |
