Product parameters
| Item | P10 |
| Pixel Pitch | 10mm |
| Pixel Configuration | 1R1G4B |
| LED Encapsulation | SMD3535 |
| Pixel Density | 10000dost/㎡ |
| Module Resoulution | 16*16(W*H) |
| Module Size | 160mm*160mm(W*H) |
| Drive Mode | 1/4 Scan |
| Cabinet Resolution | 96*96（W*H） |
| Cabinet Size（W*H） | 960mm*960mm |
| Cabinet Weight | 56±0.5kg |
| Brightness | ≥7500CD/㎡ |
| Drive Mode | 1/4 Scan |
| Max Power Consumption | 850W/㎡ |
| Average Power Consumption | 800W/㎡ |
| Best Viewing Angle | H:150°V:120° |
| Display Mode | Max1024*768/1280*1024 |
| Refresh Rate | ≥1200Hz |
| Best Viewing Distance | ≥10m |
| Protection Level | IP65 |
| Operating Voltage | AC220V/110V |
| Working Temperature | -20℃/+50℃ |
| Operating Humidity | '-20-60/10%-85% |
