Product parameters
| Item | p1.9 |
| Pixel pitch | 1.923mm |
| pixel density | 270400点/㎡ |
| module resolution | 104*78 |
| module size | 200*150*2 |
| configuration | 1R1G1B |
| Encapsulation | SMD1515 |
| Operating voltage | AC:110V-240V、50-60Hz |
| Drive mode | MBI5153/ICN2053 |
| Cabinet material | Die-casting Aluminum |
| Cabinet weight | 3.5kg |
| Cabinet resolution | 208*156 |
| Cabinet size（mm） | 400*300*55 |
| Brightness | 200-800CD/㎡ |
| Color temperature | 2000K-9500K(adjustable) |
| Viewing angle | H:160°V:160° |
| planeness | ≥98% |
| space | ＜0.1mm |
| Max power consumption | ≤500W/㎡ |
| Average power consumption | 100W/㎡-300W/㎡ |
| Frame Frequency | 60Hz |
| Refresh Rate | 1920-3840HZ |
| Grey | 16384 |
| Protection Level | IP41 |
| Lifetime | 10万小时 |
| Working Temperature | 10%-90%RH |
| Operating Humidity | -10～60℃ |
| software | Windows XP,WIN7/8/10 |
