The LED screen includes three parts: live broadcast, match time, local time and scorecard control system, plus a display in the stadium, a circular LED screen hanging in the stadium, and an advertising screen standing around the stadium.It allows the audience to feel the screen very shocking effect, so that you have a different visual experience and enjoy.It can not only live live video of basketball games, but also widely used in addition to basketball games.Sports course LED display compared with other full-color LED screen main differences:1. The LED full color display adopts high visual display technology, which makes the display content get more extensive viewing angle and higher refresh rate, and ensure the quality of video display.2. The control system of the LED large screen in the stadium is dual system. The backup system can be used when the control system is abnormal, so as to ensure that the audience do not miss every moment of the game.3. The software of the sports court screen can realize the function of multi-window display, that is to say, it can be divided into multiple screens on one screen according to the needs of the client, and different areas display different contents simultaneously, including the competition screen.Match time, competition score and team member introduction and so on different content.
Item | P6 | P8 | P10 |
Pixel Pitch | 6mm | 8mm | 10mm |
Pixel Configuration | 1R1G2B | 1R1G3B | 1R1G4B |
LED Encapsulation | SMD3535 | SMD3535 | SMD3535 |
Pixel Density | 27777dot/㎡ | 15625dot/㎡ | 10000dot/㎡ |
Module Resoulution | 32*32(W*H) | 32*16(W*H) | 16*16(W*H) |
Module Size | 192mm*192mm(W*H) | 256mm*128mm(W*H) | 160mm*160mm(W*H) |
Drive Mode | 1/8 Scan | 1/4 Scan | 1/4 Scan |
Cabinet Resolution | 96*96(W*H) | 128*96(W*H) | 96*96(W*H) |
Cabinet Size(W*H) | 576mm*576mm | 1024mm*768mm | 960mm*960mm |
Cabinet Weight | 8±0.5kg | 50±0.5kg | 56±0.5kg |
Brightness | ≥6000CD/㎡ | ≥6000CD/㎡ | ≥7500CD/㎡ |
Color Temperature | 3200-9300K/Adjustable | 3200-9300K/Adjustable | 3200-9300K/Adjustable |
Max Power Consumption | 800W/㎡ | 800W/㎡ | 850W/㎡ |
Average Power Consumption | 300W/㎡ | 300W/㎡ | 300W/㎡ |
Best Viewing Angle | H:150°V:120° | H:150°V:120° | H:150°V:120° |
Display Mode/Max | 1024*768/1280*102 | 1024*768/1280*1024 | 1024*768/1280*1024 |
Refresh Rate | ≥1200Hz | ≥1200Hz | ≥1200Hz |
Best Viewing Distance | ≥6m | ≥8m | ≥10m |
Protection Level | IP65 | IP65 | IP65 |
Maintain Style | Maintain | Maintain | Maintain |
Operating Voltage | AC220V/110V | AC220V/110V | AC220V/110V |
Working Temperature | -20℃/+50℃ | -20℃/+50℃ | -20℃/+50℃ |
Operating Humidity | 10%-85% | 10%-85% | 10%-85% |
